Waterproof 4-leds SMD 3528 LED Module

Waterproof 4-leds SMD 3528 LED Module

Shenzhen, China
Production capacity:
20000 Piece / Week
Shenzhen, China
Company
86-755-8619 7905
Judy Xiong
Contact person

Basic Information

LED Module Waterproof 4-LEDs SMD LED Module1. Light source: 4pcs super bright SMD LEDs 2. IP 65 protection rate 3. Beaming angle: 120, high brightness output, No spot; No shadow. 4. Easy installation with two mounting holes and 3M adhesive tape on the back. 5. Available Color: Red, Yellow, Blue, Green and White 6. Special design of appearance makes it unique and looks nice 7. Application: Backlight of signage, channel letter, signs, and light box and so on. 8. Attention: Please do not install it in totally exposed outdoor environment. Item No.Size InputVoltageCurrent(mA)ConsumptionWattsIntensityQty ofLEDMax of OneSingle Loop3528-SMD-4R42*28*5.9mm12VDC40mA0.48W5.2lm4503528-SMD-4Y42*28*5.9mm12VDC40mA0.48W8lm4503528-SMD-4B42*28*5.9mm12VDC40mA0.48W4lm4503528-SMD-4G42*28*5.9mm12VDC40mA0.48W12lm4503528-SMD-4W42*28*5.9mm12VDC40mA0.48W27.5lm450

Delivery terms and packaging

Packaging Detail: 50pcs/white box, 20boxes/carton Delivery Detail: 7-20 working days for different quantity
Port: ShenZhen, China

Payment term

Telegraphic transfer

Western Union
